Description
Overview
The BendPak P-9000LTF is a 9,000 lb capacity low-rise scissor lift built in an open-center, pit-style, flush-mount configuration. It is one of the highest-capacity low-rise lifts in its class and is sized for fast-lube pits and wheel-service bays that need full lifting power without sacrificing floor space.
Mounted flush with the concrete, the lift sits at a 4 in lowered height and effectively disappears when not in use, leaving the bay open for other work. The open-center design clears the wheels for tire and brake service, while a dual-pump 1.5 HP electric-hydraulic power unit with a built-in proportioning valve drives smooth, single-hand operation. An optional arm and adapter set extends reach for high-stance trucks and SUVs.
Key Features
- 9,000 lb lifting capacity - Reinforced parallel arms and an upper platform support heavier inboard loading than most low-rise lifts.
- Flush-mount, zero-footprint install - Recesses into the floor for a drive-over option that frees the bay when the lift is down.
- Open-center pit-style design - Mounts outside the pit rail without crowding the center work area, converting fast-lube pits into wheel-service bays.
- Dual-pump 1.5 HP power unit - A 1.5 HP electric-hydraulic unit with a built-in proportioning valve and push-button controls runs the lift with one hand.
- Pneumatic multi-position locks - Automatic safety locks with air release allow safe, remote lowering and avoid the maintenance of older spring releases.
- Rubber lift blocks - Durable rubber-topped pads and solid rubber blocks add height and speed setup; lifting height reaches 27 in with the block.
Specifications
| Brand | BendPak |
|---|---|
| Type | Low-Rise Scissor Lift, Open-Center Pit-Style, Flush-Mount |
| Lift Type | Low-rise scissor |
| Capacity | 9,000 lb |
| Lifting Height | 24 in (27 in with block) |
| Lowered Height | 4 in |
| Platform Length | 58.5 in |
| Platform Width | 24 in |
| Overall Length | 74.4 in |
| Speed of Rise | 55 seconds |
| Motor | 1.5 HP |
| Power | 208-230 VAC / 60 Hz / 1 Ph |
| ALI ETL Certified | Yes |
| Shipping Weight | 1,210 lb |
| Shipping Dimensions | 52 in x 77 in x 11 in |
How It Compares
| Attribute | P-9000LTF | P-9000LT |
|---|---|---|
| Mounting | Flush / pit-style | Surface mount |
| Capacity | 9,000 lb | 9,000 lb |
| Lowered Height | 4 in (recessed) | Surface ramps |
| Center Design | Open-center | Open-center |
Key Facts
- 9,000 lb capacity, among the highest-rated low-rise scissor lifts in its class (BendPak P-9000LTF specifications).
- 24 in lifting height, 27 in with the rubber block, 4 in lowered height (BendPak P-9000LTF specifications).
- 1.5 HP electric-hydraulic power unit on 208-230 VAC single-phase, 60 Hz (BendPak P-9000LTF specifications).
- ALI certified per the BendPak product listing and the ALI directory of certified lifts.
Who It's For
This lift fits high-throughput lube and service shops that want a flush-mounted, full-wheel-service low-rise lift that recesses out of the way when idle. Plan for a 208-230V single-phase circuit, a shop air supply for the lock release, and a prepared floor recess for the flush mount.
Shipping and Freight
The P-9000LTF ships as Oversize freight at roughly 1,210 lb. Plan for freight handling and a forklift at delivery. Flush mounting requires a prepared recess in the concrete, so confirm your install plan and request a freight quote before ordering. For broader shop setup, browse our auto service equipment.
About BendPak
BendPak builds and supports its lifts from Agoura Hills and Santa Paula, California, and is a member manufacturer of the Automotive Lift Institute. You can see the full BendPak lineup across our catalog.
Frequently Asked Questions
What is the advantage of the flush mount?
The lift recesses into the floor at a 4 in lowered height, so it nearly disappears and frees the bay for other work when not in use.
Can it service wheels and brakes?
Yes. The open-center design clears the wheels and converts a fast-lube pit into a wheel-service bay.
Is it ALI certified?
Yes. The P-9000LTF is listed as ALI certified by BendPak and appears in the ALI directory of certified lifts.
What power does it need?
A 1.5 HP power unit on 208-230 VAC single-phase, 60 Hz, plus a shop air supply for the pneumatic lock release.
How is it different from the P-9000LT?
The P-9000LT is the surface-mount version. The P-9000LTF is built to recess flush into a pit in the floor.
Talk to a specialist about power, shop air, floor prep, and freight before you order.
